Description
Technical index
Marking format: 110×110, 160×160, 220×220, etc.
Font size: 0.5*0.5 square mm ~ 100*100 square mm.
Minimum adjustment range: 0.01mm.
Printed characters: can print commonly used Chinese characters and English letters and any graphics
Others can be designed according to user requirements
Marking speed: 1--10000mm/ SEC.
Marking form: conventional models can be flat printed linear, circular arc. The rotary model can print the outer round surface of the circular workpiece.
Date and time: batch, shift, automatic progress, factory standard, etc.
Temperature: -5 Cº to 50 Cº.
Relative humidity: 25 Cº--85%
Power supply: AC220V±15V,50±1Hz.
Power: P≤1KW.
Floor area: 1.0 square meters.
