Technical Parameters:
1. Control range
Curing stage: Temperature: room temperature to 75, Moisture: above 95
Drying stage: Temperature: room temperature to 80, Moisture: below 10
2. Control accuracy
Temperature: setting value +1
Curing moisture: setting value +2-RH
3. Process conversion rate
Temperature: 3 minutes Moisture:2…RH /3 minutes
4. Breakage Testing Device
when the heater is broken and cannot continue to heat up, the system will alarm and display that the heater is damaged and cannot heat up.
Current Testing Device: when the solid-state relay has short circuit and continue to heat up, the testing device will alarm and display that the solid-state relay is damaged, and stop heating up.
