Technical parameters:
1. Applicable grid dimension: Length = 280-380mm, Width = 120-168mm, Thickness = 1.0-4.5mm (according to the customer's drawings )
2. Production capacity: 60-100 big panels/min
3. Reject rate: 1.0%, the premise is that the buyer should provide plate deformation less than 0.5 mm
4. Adjustable range of guiding device: 280-380 mm5. Cutter size: 150.3X 50.83X5.0 (mm)6. Main chain size: pitch size 25.4X177. Suction opening size: 150 mm
8. Infrared ray induction with automatic account
9. Main motor size: gear motor power is 2.2KW, reduction ratio is 1/30
10.Power supply and power consumption: AC380V±10%, 50Hz, 9.5kw
11. Air pump parameter: power is 2.2KW, maximum discharge is250m³/h, vacuum (100KPa)
12. Total weight of machine:3.0T
13. Rolling cutting machine dimension: L*W*H= 6100*1450*1700 mm
14. Collection table: it is driven by the belt, it can stack the plates automatically
