Description
1.Equipment parameters:
Power supply:AC380V/50HZ.
Air source:0.6~0.8MPa, clean and dry air
Rated power:30KW
Production efficiency:12V12AH 600 batteries (two cavities) per8hours 12V7AH 800 batteries (three cavities) per 8 hours.
Equipment weight:1.2 tons
2.Equipment characteristics:
2.1This machine adopts temperature control mode for cast welding. When the demoulding temperature reaches the setting temperature, the battery can be released from the COS mould, to ensure battery cast-welding quality.
2.2 Welding speed: 40-80s/mould (2-3 batteries from 1 mould; for 6V4Ah specification, 9 batteries from 1 mould).
2.3 Small occupied space, easy operation, fully-sealed design, safe and environment-friendly.
3.Performance advantages:
3.1 All control can be realized through advanced intelligent PLC interface. The interface can intuitively reflect all technical parameters on-site work.
3.2 Intelligent design, reliable running, easy operation, no special requirements for employees.
