Microprocessor control, digital display, small size, easy to operate.
Can be prepared on the controller 1-32 process (set), and automatic operation.
Can be prepared on the computer 1-32 process, and the automatic operation of the controller.
With the plate formation and battery formation control mode.With the constant current charging,constant current limit voltage charging,constant current discharging.reverse charging(plate formation),static,cycle and so on.
Has the power cut data to keep, the telephone call automatic recovery operation and so on function.
Can store more than 1400 of the recorded data (every 1-60 minutes automatically recorded at the time), and can be transmitted to the computer to save, display, print.
Flow, flow detection, lack of power, positive and negative disconnection, reversed fault detection function.
Multi machine communication function, can achieve up to more than 135 controllers centralized management of the computer.
Manual / Automatic function.
Error operation preventing function.
Technical specifications
AC input: three phase four wire AC380V, 50HZ.
Input voltage change:±
DC output current: 0-300A.; 0-300A
DC output voltage: 0-350V.
Control panel input voltage: AC16V, current consumption <200mA.
Controller unit input voltage: AC18V, current consumption <100mA.
Photoelectric isolation communication unit input voltage: AC9V, current consumption <100mA.
Analog cell input voltage: + / - DC12V, current consumption <50mA.
Current analog input: 0~5V, corresponding to the maximum range of 300.0A.
Voltage analog input: 0~5V, the maximum range of the corresponding voltage 350.0V.
Given analog output: 0~5.5V.
The relative precision of current control: setting the constant current value of + 0.5%.
The relative precision of voltage control: setting the constant pressure value of 0.5%.
Cooling mode: self cooling or air cooling.
Communication device: RS232/485 universal interface, DC9V power.
