Introduction
1 Model: BP580-B2 (double systems metering)
2 Production Capacity: 12V100Ah, 200pcs/hr
3 Dimension (L*W*H): 1800mm×1100mm×1800mm
4 Applicable Epoxy/Glue: epoxy for cover dispensing
5 Proportion: 100:100~100:10, adjustable
6 Working Range: 600 (X)* 600 (Y)* 100 (Z) mm
7 Station: double stations, each station size is 300 (W)*600(L)*80(H)
8 Proportion Accuracy: ±3%
9 Glue Output Accuracy: ±3g (when the glue output volume is ＞1g)
10 Metering method: servo motor + gear pump
11 Transmission method: servo motor
12 Power: AC380V, 50HZ, 0.5-1.5KW
13 Working temperature: Moisture 20~90%, Temperature 0~40℃
