Technical Parameters:
*Total power: 15KW (note: the standard input voltage is 380V. For other voltages, 20KVA transformer is required.)
*Compressed air: ≥ 0.6MPa (in order to ensure stable and normal operation of the system, the system contains 1m3 air reservoir)
1.Distribution speed of cutter head: 0-1420 RPM (can be set freely through human machine interface, diameter of large cutter head: 250mm)
2.High and low speed mixing tank volume: 300L (maximum single dispersion quantity ≤200L, minimum quantity ≥50L);
3.Stirring time: time and speed can be set in any section;
4.High precision precise metering pump flow (to load sulfuric acid or pure water): time setting (1500L/H);
5.Pneumatic diaphragm pump flow (conveying between high and low speed mixing tanks and conveying between low speed mixing tank and gel filling machine) : time setting (4000L/H);
6.Operating temperature: < 45℃ (the temperature of the control panel is displayed in real time. In order to ensure the gel quality, when the gel temperature reaches 45℃, it will automatically alarm and stop stirring)
7.Gel preparation proportion (silicon dioxide/total weight) : can be set freely, the allowable proportion range of equipment ≥0.5%, ≤17% (motor power limit);
8.Working efficiency: 200L gel can be made per hour (according to the proportion of 10%), about 40 batteries of 12V100AH or 20 batteries of 12V200AH can be filled; (if the proportion decreases, the work efficiency will increase, and vice versa)
