Technical Indicators
1. Voltage: 380 v, three to four lines, 50 Hz.
2. Installed power: 28.8 kw/h.
3. The actual use of power: 15 kw/h or less
4. Single equipment set: use 1 standard lead ingot (45 kg per ingot), granulation meets normal production requirements for one 24T ball mill machine or two 14T ball mill machines
5. Granulation size: 25 * 25 * 17 mm to 20 mm
6. Grain weight: 75 ~ 100 g + 15 g
7. Production: 2.5 T/H ~ 2.75 T/H
8. Applicable air pressure: not less than 0.4-0.7 Mpa
9. Suitable water pressure: 0.2 Mpa
10. Water temperature: 10 ℃ to 25 ℃
11. Granulation equipment export height: 350 m
12. Hydraulic oil for Equipment> Great Wall brand anti-wear hydraulic oil L - HM46
13. Equipment specification：
◆ The host 3028mm×1040mm×2100mm.
◆ Vice machine 2200mm×760mm×1450mm
◆ Lead grain of scraper conveyor 1450㎜×350㎜×1250㎜。
14. Weight of the whole machine: about 4 T
