Main Technical Parameters
1. Oxide filling length: 320mm.
2. Oxide filling efficiency: 45 plates/time, about 3mins/cycle, 5000pcs/8 hours;
3. Oxide filling density: 3.6g/cm3.
4. Oxide filling Consistency: 80% grids reach ±10g for 6V/12V electric vehicle batteries.
5. Automatic weighing system: 500kg/ time.
6. High efficiency oxide mixing weighing: 500kg/ time, mixing time: 10-15min.
7. The frequency inverter controls the vibration force to ensure different vibration parameters of the grid.
8. With negative pressure vent, the equipment is fully sealed when working.
