Technical specifications
l AC input: three phases four wires AC400V, 50HZ. (can be customized according to the customer)
l Input voltage change:±2%
l DC output current: 0-250A; 0-250A. (or customized)
l DC output voltage: 0-300V. (or customized)
l Control panel input voltage: AC16V, current consumption < 200 mA.
l Controller unit input voltage: AC18V, current consumption < 100 mA.
l Photoelectric isolation communications unit input voltage: AC9V, current consumption < 100 mA.
l Simulation unit input voltage: ±DC12V, current consumption < 50 mA.
l Current analog input: 0 to 5 V, corresponding to the current full range maximum 250.0 A
l Analog input voltage: 0 to 5 V, corresponding to the voltage full range maximum 300.0 V.
l Given the analog output: 0-5.5 V
l Current control relative accuracy: set constant current value ±0.5%
l Voltage control relative accuracy: set constant voltage value ±0.5%.
l Cooling method: natural cooling or air cooling.
l Com: RS232/485 common interface, DC9V power supply.
