Technical parameter:
1.Transport chain speed: 12~25m/min Conveyor chain (material 316L)
2.Productivity (up to 130 Panels / min)
3.The adjustable temperature of the drying oven: Room temperature ~ 180
4.Power supply capacity and related parameters:
5.Transmission chain main drive motor reducer (1 PC): N=0.75KW
6.Humidifying fan(1 PC): Nu=2.2kW
7.Thermal circulation fan(1 PC): N=11KW
8.Liquefied gas comsumption:2.3-11.8m3/h; Natural gas: 6-30m3/h
9.Dimension: Length*width*Height=11700 x 1250 x 2500mm
10.Equipment content: 1 main FDO, 1 electrical control cabinet and 1 pc Collecting frame.
